GSM Auto Dialler & Hard Wired IR Beam or PIR Sensor Kit

GSM Auto Dialler & Hard Wired IR Beam or PIR Sensor Kit

From £110.00 Excl. VAT

The Auto Dialler & PIR Sensor Kit is ideal for home installations. When the PIR sensor is broken the auto dialler will alert you by text or call.

  • Quad band freq 850/900/1800/1900
  • 4G Bands – B1/B3/B5/B7/B8/B20 (others on request)
  • Power Supply Voltage: 9 -24 volts DC – 1 Amp max.
  • Current used in standby mode: 60mA max.
  • IP 65 Enclosure rating for outside installation.
  • 8 Amp Relay Output
  • No landline required
  • Micro 2G or 4G simcard.
  • Dimensions L150 xW90 xH45mm.
  • Dimensions PCB Only: L125 x W67mm
  • Operating Temperature: -10…+40°C
  • Text for signal strength.
  • Sim Active Function.
  • Programmed by Text.
  • 2 Inputs
SKU: N/A Category:


Overview of the GSM Auto Dialler & IR Beam or PIR Sensor Kit

Our GSM Auto Dialler & IR Beam or PIR Sensor is a standalone alarm suitable for indoor use. The PIR (Passive Infrared) and IR beams are motion detectors. When attached to the GSM Auto Dialler they detect movement. The Auto Dialler will send a text or call to you so you are aware of a possible intrusion. This is done using GSM technology. Therefore you could be anywhere in the world and be notified of a possible problem.

Why choose the GSM Auto Dialler & IR Beam or PIR Sensor Kit

An advantage of this GSM Auto Dialler & IR Beam or PIR Kit is that it has both inputs and outputs which enable customers to set the unit up so that they can send commands to the auto dialler as well as receive updates.

For Example. The PIR sensor is triggered. The auto dialler will then send you a message or call. You then have the ability to text the unit back to switch on a siren or light.

Customers can use the GSM Auto Dialler & IR Beam or PIR Sensor Kit worldwide as it has been manufactured using the quad band frequency. We frequently ship models all over Europe, Australia and USA with great feedback. Customers who purchase this can also install the auto dialler outside as the box is perfectly weathered. We test all of our units are in high heats and freezing weather conditions. We are so confident in the products reliability and durability that we now offer a two year product warranty and will replace any faulty models in that timescale.

2G or 4G?

Some countries have begun to shut down their 2G networks such as USA. There is no set date for this to happen in the UK at present. However, in some areas customers may find they have a better signal using either 2G or 4G. We have stopped selling 3G due to 3G frequency being shutdown end of 2022


Additional information


2G, 4G


Beam, PIR
